Factory Lead Time

10 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

6-SIP Module, 4 Leads

Weight

2.099991g

Operating Temperature

-40°C~85°C

Published

2006

Series

VIBLSD1-SIP (1W)

Packaging

Tube

Size / Dimension

0.77Lx0.24W x 0.40 H 19.6mmx6.0mmx10.2mm

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

4

Type

Isolated Module

Applications

ITE (Commercial)

Max Power Dissipation

1W

Terminal Position

SINGLE

Terminal Form

PIN/PEG

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

1

Terminal Pitch

2.54mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Pin Count

6/4

JESD-30 Code

R-PSMA-P4

Number of Outputs

1

Efficiency

71%

Voltage - Isolation

1kV

Voltage - Input (Max)

5.25V

Output Voltage

12V

Max Output Current

83mA

Voltage - Input (Min)

4.75V

Input Voltage-Nom

5V

Trim/Adjustable Output

NO

Output Power

1W

Current - Output 1

83mA

Total Power Output-Max

1W

Isolation

Isolated

Features

SCP

Height

10.16mm

RoHS Status

RoHS Compliant

Lead Free

Lead Free
